PRODUCT INFORMATION
The Haffmans CO2 Evaporation Heat Recovery System - LiquiVap is a heat exchanger designed to automatically evaporate liquid CO2 running from the CO2 storage tank(s). The required evaporation heat is provided by available ‘hot’ cooling medium, which during the evaporation process is cooled down. In this manner energy is saved which would otherwise be required by the cooling medium-cooling unit to lower the temperature of the cooling medium. This system operates parallel to the customers sites cooling medium system with bypass, valves and cooling medium pump care of the customer.
Benefits
- Reduces energy consumption up to 60 %
- Improves the operation efficiency while reducing operating costs
- Compact, modular energy saving system with optional gas superheater
- Combined CO2 vaporization and condensing pressure control
- Automatic purge gas system for minimized CO2 loss
- Pre-piped for speedy installation
- Fully automatic operation
- Can operate at lower refrigeration temperature, resulting in additional CO2 recovered through earlier fermenter turn in.
- Reduced operating hours of liquefying refrigerant compressors (longer life) and thus reduced maintenance
- Easily retrofits into existing systems
-
FUNCTIONAL DESCRIPTION
-
The required evaporation heat is provided by available hot and cooling medium, which during the evaporation process is cooled down. In this manner energy is saved which would otherwise be required by the cooling medium-cooling unit to lower the temperature of the cooling medium. This system operates parallel to the customers sites cooling medium system with bypass, valves and cooling medium pump care of the customer.
Pentair Haffmans LiquiVap operate successfully in many parts of the especially in industries where CO2 is recovered and consumed onsite such as:
- Brewing
- Wine
- Cider
- Natural water well / spring
- Biogas Upgrading
The LiquiVap integrated into the CO2 recovery process, runing parallel to the Liquefaction System and CO2 vaporizers.
- Brewing
DOWNLOADS
| TITLE | DOWNLOAD PDF | |
| Brochure | Haffmans CO2 Heat Recovery System - LiquiVap | Download |
| Case study | Haffmans LiquiVap - Guiness | Download |
| Case study | Haffmans LiquiVap - Molson Coors | Download |
| Leaflet | CO2 Recovery Plants | Download |
| Technical documentation | Looking for operating instructions, installation manual, spare part list etc.? | Please, send us your request |
